Description
| GENERAL INFORMATION | |
| Brand | Lenovo |
| Product Series | ThinkPad X1 Yoga Gen 6 |
| Model | ThinkPad X1 Yoga Gen 6 |
| Release Year | 2021 |
| Form Factor | 2-in-1 Convertible Laptop |
| Operating Modes | Laptop, Tablet, Tent, Stand |
| Color | Storm Grey |
| PROCESSOR | |
| Processor | Intel Core i7-1165G7 |
| Generation | 11th Generation Intel Core |
| Cores / Threads | 4 Cores / 8 Threads |
| Base Frequency | 2.8GHz |
| Maximum Turbo Frequency | Up to 4.7GHz |
| Cache | 12MB Intel Smart Cache |
| GRAPHICS | |
| Graphics | Intel Iris Xe Graphics |
| Graphics Type | Integrated |
| Graphics Memory | Shared System Memory |
| MEMORY & STORAGE | |
| RAM | 16GB LPDDR4x-4266 |
| RAM Configuration | Soldered, not upgradeable |
| Storage | 512GB M.2 2280 PCIe 4.0 NVMe SSD |
| Storage Upgrade | One M.2 SSD; support up to 2TB according to Lenovo specifications |
| DISPLAY | |
| Screen Size | 14 inches |
| Panel Type | IPS |
| Resolution | 1920 × 1200 (WUXGA) |
| Aspect Ratio | 16:10 |
| Brightness | 400 nits for the specified WUXGA panel configuration |
| Color Gamut | 100% sRGB for the specified WUXGA panel configuration |
| Touchscreen | 10-point multi-touch |
| Hinge | 360-degree convertible hinge |
| Pen | Integrated, rechargeable Lenovo Pen |
| CAMERA & AUDIO | |
| Camera | 720p HD camera with privacy shutter; IR camera depends on configuration |
| Microphones | 4-microphone array |
| Speakers | Stereo speakers with Dolby Atmos |
| Audio Jack | 3.5mm headphone/microphone combo jack |
| CONNECTIVITY | |
| Wi-Fi | Intel Wi-Fi 6 AX201 |
| Bluetooth | Bluetooth 5.1; hardware supports Bluetooth 5.2 |
| WWAN | Optional on supported configurations |
| PORTS | |
| Thunderbolt | 2 × Thunderbolt 4 / USB-C, up to 40Gbps |
| USB Type-A | 2 × USB 3.2 Gen 1, one Always On |
| HDMI | 1 × HDMI 2.0 |
| SIM Slot | Optional Nano-SIM slot on supported WWAN configurations |
| KEYBOARD & SECURITY | |
| Keyboard | Backlit, spill-resistant keyboard |
| Pointing Device | TrackPoint and multi-touch touchpad |
| Fingerprint Reader | Integrated into power button |
| Security Chip | TPM 2.0 |
| Camera Privacy | Physical privacy shutter |
| BATTERY & POWER | |
| Battery Capacity | 57Wh integrated battery |
| Power Adapter | 65W USB-C adapter, depending on regional configuration |
| DESIGN & DIMENSIONS | |
| Dimensions | 314.4 × 223 × 14.99mm |
| Weight | Starting at approximately 1.399kg |
| Chassis | Aluminium top and bottom |
